Collet ER 32


Price:
Rs. 275
Stock:
In stock

Description

DESCRIPTION

  • ER32 Collet follows DIN 6499 standard
  • The standard ER collet is the most widely used clamping system in the world
  • Made from EN-47 Alloy spring steel for spring action and fully hardened
  • ER Standard Precision Collet with 10 microns run out
  • Install into an ER collet chuck or holder to tightly grip round-shank tool bits in milling machines.

The proper way to fit RR ER32 Collet to a suitable nut:

  • The Collet must always be inserted into the nut before setting the tool into the collet
  • The collet is fitted inside the nut by applying slight pressure A
  • It is removed by applying Pressure to the collet
  • Never tighten the chuck without a correct size tool shank being present in the collet

Application: ER32 collets are ideal for many machining operations such as

  • Boring
  • Milling
  • Reaming
  • Tapping
  • Grinding

Suitable Products:

  • Carbide End Mills
  • ER Collet Chucks (BT/CAT/HSK/ISO/MT/R8/SK/Straight Shank)
  • ER Collet Chuck Nuts
  • ER Collet Chuck Spanners
  • Pull Stud (Retention Knob)
  • Locking Fixtures




ER DIA CLAMPING CODE
32 0.5 0.1-0.5 MCT0102
32 1 0 - 1.0 MCT0103
32 1.5 1-1.5 MCT0104
32 2 1.0 - 2.0 MCT0105
32 2.5 1.5-2.5 MCT0106
32 3 2.0 - 3.0 MCT0107
32 3.17 3-3.5 MCT0108
32 3.5 2.5-3.5 MCT0109
32 4 3.0 - 4.0 MCT0110
32 4.5 3.5-4.5 MCT0111
32 5 4.0 - 5.0 MCT0112
32 5.5 4.5-5.5 MCT0113
32 6 5.0 - 6.0 MCT0114
32 6.35 6-6.35 MCT0115
32 6.5 5.5-6.5 MCT0116
32 7 6.0 - 7.0 MCT0117
32 8 7.0 - 8.0 MCT0118
32 9 8.0 - 9.0 MCT0119
32 10 9.0 - 10.0 MCT0120
32 11 10.0 - 11.0 MCT0121
32 12 11.0 - 12.0 MCT0122
32 13 12.0 - 13.0 MCT0123
32 14 13.0 - 14.0 MCT0124
32 15 14.0 - 15.0 MCT0125
32 16 15.0 - 16.0 MCT0126
32 17 16.0 - 17.0 MCT0127
32 18 17.0 - 18.0 MCT0128
32 19 18.0 - 19.0 MCT0129
32 20 19.0 - 20.0 MCT0130
32 21 20.0-21.0 MCT0131
32 22 21.0-22.0 MCT0132
32 23 22.0-23.0 MCT0133
32 24 23.0-24.0 MCT0134
32 25 24.0-25.0 MCT0135
