AHU Series Cutter Body — JDMT Insert Compatible

AHU Series Cutter Body — JDMT Insert Compatible

Rs. 1,664 (Incl. of all taxes)
Rs. 1,664 (Incl. of all taxes)
Rs. 1,410.17 + Rs. 253.83 GST
Sale Sold out
Taxes included. Shipping calculated at checkout.
GST invoice All prices include 18% GST
Delhi dispatch Ships from Chandni Chowk stock
Shipping Standard Rs. 70 below Rs. 2,999 · Free standard delivery on Rs. 2,999+ · Express Rs. 120
Bulk quote Message us on WhatsApp

AHU Series Cutter Body — JDMT Insert Compatible

AHU Series indexable cutter range listed for JDMT10 and JDMT15 inserts. The current selector combines straight-shank bodies with one compact face-mill configuration.

How to read the option code

  • Example: C25-S25-200L/JDMT15-2T.
  • C25 = 25 mm cutter diameter.
  • S25 = 25 mm shank diameter.
  • 200L = 200 mm listed length.
  • JDMT15 = listed insert or cutter-family designation.
  • 2T/T2 = 2 insert pockets.

Variant guide

Current option Configuration Cutter dia. Connection Length Insert / series Pockets
C16-S16-200L/JDMT10-2T Straight shank 16 mm 16 mm 200 mm JDMT10 2
C20-S20-200L/JDMT10-2T Straight shank 20 mm 20 mm 200 mm JDMT10 2
C25-S25-200L/JDMT10-3T Straight shank 25 mm 25 mm 200 mm JDMT10 3
C25-S25-200L/JDMT15-2T Straight shank 25 mm 25 mm 200 mm JDMT15 2
C32-S32-200L/JDMT15-3T Straight shank 32 mm 32 mm 200 mm JDMT15 3
C50-S22-48L/JDMT15-4T Face-mill body 50 mm 22 mm 48 mm JDMT15 4

How to select

Choose the construction first, then match the shank or mounting-bore diameter and select the required cutter diameter.

Confirm the exact AHU manufacturer/model, JDMT insert suffix and package contents before ordering.
