CCMT120404-SL1 Turning Insert — Atomix

Name: CCMT120404-SL1 Turning Insert — Atomix
Brand: Midland Tools
SKU: 49419999805680
Price: 3835.0 INR
Availability: InStock

Rs. 3,835 (Incl. of all taxes)

Rs. 3,250 + Rs. 585 GST

Sale Sold out

Taxes included. Shipping calculated at checkout.

CCMT120404-SL1 Turning Insert — Atomix

Atomix CCMT120404-SL1 carbide turning insert (80° Diamond, 7° clearance) — designed for CNC lathe turning, boring and facing on shafts, bushings and precision components. Positive rake geometry and precision-ground edges cut cleanly through carbon steel, stainless steel, cast iron, and hardened materials up to HRC 45. Box of 10 pieces.

Also searched as: CCMT120404-SL1 insert, CCMT120404-SL1 tip, carbide turning bit, CCMT CNC tip.

Specifications

ISO Code	CCMT120404-SL1
Shape	C — 80° Diamond
Clearance	C (7°)
Dimensions	IC 12.7 mm, thickness 4.76 mm, nose radius 0.4 mm
Pack size	Box of 10 pieces
Brand	Atomix

Typical cutting parameters

Workpiece	Vc (m/min)	Fn (mm/rev)	Ap (mm)
Carbon steel	140–220	0.08–0.25	0.3–2.0
Stainless steel	80–160	0.08–0.20	0.3–2.0
Cast iron	100–200	0.10–0.30	0.5–3.0
Hardened steel (HRC 45)	60–120	0.05–0.15	0.2–1.0

Starting values — adjust for rigidity, coolant, and finish requirement.

Cross-brand grade equivalents

Atomix Grade (application)	Equivalents
AX3220 M — Stainless steel, medium cuts, anti-BUE coating	Korloy NC6210/PC8110 · Deskar LF9018 · Mitsubishi US735 · Widia WS40

Directional equivalents by ISO application class. For critical work, verify against current brand datasheets.

Chipbreaker suffix guide

Suffix	Use case
HQ	High-quality finishing geometry — low feeds, best surface finish.
MV	Medium-versatile — forgiving on mixed steel/stainless shops.
WM	Wide-medium for heavy duty, deeper cuts.
EM	General medium cutting — good chip control over wide feed range.
FG / FM	Fine finishing — excellent surface finish at low feeds.
HM	Hard-material chipbreaker — short chips in HRC 40+ work.
