TPMH090204-MV AX3220 Turning Insert — Atomix
TPMH090204-MV AX3220 Turning Insert — Atomix
Price shown is for 1 loose insert piece.
Couldn't load pickup availability
TPMH090204-MV AX3220 Turning Insert — Atomix
Atomix TPMH090204-MV carbide turning insert (Triangle, 11° clearance) — designed for CNC lathe turning, boring and facing on shafts, bushings and precision components. Positive rake geometry and precision-ground edges cut cleanly through carbon steel, stainless steel, cast iron, and hardened materials up to HRC 45. Loose single insert piece.
Also searched as: TPMH090204-MV insert, TPMH090204-MV tip, carbide turning bit, TPMH CNC tip.
Specifications
| ISO Code | TPMH090204-MV |
| Shape | T — Triangle |
| Clearance | P (11°) |
| Dimensions | IC 9.525 mm, thickness 2.38 mm, nose radius 0.4 mm |
| Pack size | Loose single insert piece |
| Brand | Atomix |
Typical cutting parameters
| Workpiece | Vc (m/min) | Fn (mm/rev) | Ap (mm) |
|---|---|---|---|
| Carbon steel | 140–220 | 0.08–0.25 | 0.3–2.0 |
| Stainless steel | 80–160 | 0.08–0.20 | 0.3–2.0 |
| Cast iron | 100–200 | 0.10–0.30 | 0.5–3.0 |
| Hardened steel (HRC 45) | 60–120 | 0.05–0.15 | 0.2–1.0 |
Starting values — adjust for rigidity, coolant, and finish requirement.
Cross-brand grade equivalents
| Atomix Grade (application) | Equivalents |
|---|---|
|
AX3220 M — Stainless steel, medium cuts, anti-BUE coating |
Korloy NC6210/PC8110 · Deskar LF9018 · Mitsubishi US735 · Widia WS40 |
Directional equivalents by ISO application class. For critical work, verify against current brand datasheets.
Dispatch: Same day from Chandni Chowk, Delhi. India-wide shipping.
Need a grade not listed, cross-brand help, or a bulk quote? WhatsApp us at +91 70111 82829 — typical reply within 30 minutes during shop hours.
