CHAMFER TOOL 45 DEGREE Cutter Body
CHAMFER TOOL 45 DEGREE Cutter Body
Regular price
Rs. 1,848
(Incl. of all taxes)
Regular price
Sale price
Rs. 1,848
(Incl. of all taxes)
Rs. 1,566.10 + Rs. 281.90 GST
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
GST invoice
All prices include 18% GST
Delhi dispatch
Ships from Chandni Chowk stock
Free delivery
On orders above Rs. 2,999
Bulk quote
Message us on WhatsApp
CHAMFER TOOL 45 DEGREE Cutter Body
Indexable 45° chamfer cutter body listed for TCMT11 and TCMT16 inserts. The current option code combines a listed chamfer range, shank diameter, listed length and insert-pocket count.
How to read an option
- Example: C05--16-S16-100L/TCMT11-1T.
- 05--16 = listed chamfer range of 5–16 mm.
- S16 = 16 mm shank diameter.
- 100L = 100 mm listed overall length.
- TCMT11 = listed insert family.
- 1T = one insert pocket.
Variant guide
| Current option | Listed range | Shank | Listed length | Insert | Pockets |
|---|---|---|---|---|---|
| C05--16-S16-100L/TCMT11-1T | 5–16 mm | 16 mm | 100 mm | TCMT11 | 1 |
| C15--27-S16-100/TCMT11-2T | 15–27 mm | 16 mm | 100 mm | TCMT11 | 2 |
| C06--24-S16-100L/TCMT16-1T | 6–24 mm | 16 mm | 100 mm | TCMT16 | 1 |
| C22--40-S20-100L/TCMT16-2T | 22–40 mm | 20 mm | 100 mm | TCMT16 | 2 |
How to select
Match the shank diameter to the holder, then select the required chamfer range and TCMT insert family.
The exact meaning of the first numeric range and package contents require supplier confirmation before use on critical work.
