WCMT06T308 PA120 U-DRILL INSERT — Widia
Widia WCMT06T308 carbide drilling insert (80° Trigon, 7° clearance) — designed for indexable-insert drilling on CNC mills and lathes. Precision-ground edges cut cleanly through carbon steel, stainless steel, cast iron, and hardened materials up to HRC 45. Box of 10 pieces.
Also searched as: WCMT06T308 insert, WCMT06T308 tip, carbide drilling bit, WCMT CNC tip.
Specifications
| ISO Code | WCMT06T308 |
| Shape | W — 80° Trigon |
| Clearance | C (7°) |
| Dimensions | IC 6.35 mm, thickness 3.18 mm, nose radius 0.8 mm |
| Pack size | Box of 10 pieces |
| Brand | Widia |
Typical cutting parameters
| Workpiece | Vc (m/min) | Fn (mm/rev) | |
|---|---|---|---|
| Carbon steel | 80–150 | 0.08–0.20 | — |
| Stainless steel | 60–120 | 0.06–0.15 | — |
| Cast iron | 80–140 | 0.10–0.25 | — |
Starting values — adjust for rigidity, coolant, and finish requirement.
Cross-brand grade equivalents
| Widia Grade (application) | Equivalents |
|---|---|
|
PA120 P — Steel, premium PVD |
Atomix AX3150 · Korloy PC9030 · Deskar LF6118 · Mitsubishi VP15TF |
Directional equivalents by ISO application class. For critical work, verify against current brand datasheets.
Dispatch: Same day from Chandni Chowk, Delhi. India-wide shipping.
Need a grade not listed, cross-brand help, or a bulk quote? WhatsApp us at +91 70111 82829 — typical reply within 30 minutes during shop hours.
