VNMG160408 Turning Insert — Atomix

Name: VNMG160408 Turning Insert — Atomix
Brand: Midland Tools
SKU: 49436205285616
Price: 519.2 INR
Availability: InStock

Rs. 519.20 (Incl. of all taxes)

Rs. 440.00 + Rs. 79.20 GST

Sale Sold out

Price shown is for 1 loose insert piece.

Taxes included. Shipping calculated at checkout.

Sold loose: price shown is for 1 insert piece.

Buy any 20 or more eligible Atomix insert pieces with a base price of Rs. 200+ before GST (Rs. 236+ incl. GST) in one order and get 10% off automatically at checkout. Lower-priced variants are excluded.

VNMG160408 Turning Insert — Atomix

Atomix VNMG160408 carbide turning insert (35° Diamond, 0° clearance) — designed for CNC lathe turning, boring and facing on shafts, bushings and precision components. Positive rake geometry and precision-ground edges cut cleanly through carbon steel, stainless steel, cast iron, and hardened materials up to HRC 45. Loose single insert piece.

Also searched as: VNMG160408 insert, VNMG160408 tip, carbide turning bit, VNMG CNC tip.

Specifications

ISO Code	VNMG160408
Shape	V — 35° Diamond
Clearance	N (0°)
Dimensions	IC 16 mm, thickness 4.76 mm, nose radius 0.8 mm
Pack size	Loose single insert piece
Brand	Atomix

Typical cutting parameters

Workpiece	Vc (m/min)	Fn (mm/rev)	Ap (mm)
Carbon steel	140–220	0.08–0.25	0.3–2.0
Stainless steel	80–160	0.08–0.20	0.3–2.0
Cast iron	100–200	0.10–0.30	0.5–3.0
Hardened steel (HRC 45)	60–120	0.05–0.15	0.2–1.0

Starting values — adjust for rigidity, coolant, and finish requirement.

Chipbreaker suffix guide

Suffix	Use case
HQ	High-quality finishing geometry — low feeds, best surface finish.
MV	Medium-versatile — forgiving on mixed steel/stainless shops.
WM	Wide-medium for heavy duty, deeper cuts.
EM	General medium cutting — good chip control over wide feed range.
FG / FM	Fine finishing — excellent surface finish at low feeds.
HM	Hard-material chipbreaker — short chips in HRC 40+ work.
