Midland Tools
ZCC ONHU060408 16-Edge Face Mill Cutter
ZCC ONHU060408 16-Edge Face Mill Cutter
Regular price
Rs. 5,192
(Incl. of all taxes)
Regular price
Sale price
Rs. 5,192
(Incl. of all taxes)
Rs. 4,400 + Rs. 792 GST
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
GST invoice
All prices include 18% GST
Delhi dispatch
Ships from Chandni Chowk stock
Shipping
Standard Rs. 70 below Rs. 2,999 · Free standard delivery on Rs. 2,999+ · Express Rs. 120
Bulk quote
Message us on WhatsApp
ZCC ONHU060408 16-Edge Face Mill Cutter
ZCC-titled face-mill cutter body listed for ONHU060408/ONHU06 inserts and a 16-edge system. Options state cutter diameter, mounting bore, listed body length and insert-pocket count.
How to read the option code
- Example: C63-S22-48L/ONHU06-6T.
- C63 = 63 mm cutter diameter.
- S22 = 22 mm mounting bore or connection diameter.
- 48L = 48 mm listed length.
- ONHU06 = listed insert family.
- 6T/T6 = 6 insert pockets.
Variant guide
| Current option | Configuration | Cutter dia. | Mounting Bore Or Connection Diameter | Length | Insert | Pockets |
|---|---|---|---|---|---|---|
| C50-S22-48L/ONHU06-5T | Face-mill body | 50 mm | 22 mm | 48 mm | ONHU060408 / ONHU06 | 5 |
| C63-S22-48L/ONHU06-6T | Face-mill body | 63 mm | 22 mm | 48 mm | ONHU060408 / ONHU06 | 6 |
| C80-S27-48L/ONHU06-7T | Face-mill body | 80 mm | 27 mm | 48 mm | ONHU060408 / ONHU06 | 7 |
| C100-S32-53L/ONHU06-8T | Face-mill body | 100 mm | 32 mm | 53 mm | ONHU060408 / ONHU06 | 8 |
How to select
Match the mounting bore to the arbour, then select cutter diameter and pocket count.
Confirm the exact ZCC/ZCC-CT model, ONHU insert geometry and package contents before ordering.
